South Design Studio

Jaguar's new dedicated purpose-built design studio is a creative space and is part of the redeveloped design and engineering centre at Gaydon.
Project Stats
8

services

£1.5

million

Hartle Ltd provided a full mechanical design and build turnkey package for a refurbishment and extension to the Jaguar Land Rover, Gaydon, South Design Facility.

Project Scope/Services: LTHW heating, domestic hot & cold water, above ground drainage, VRF air conditioning, mechanical heat recovery ventilation, 3-way mixing box ventilation c/w DX heating/cooling coils, natural gas services and a building energy monitoring system. Also, refurbishment of existing AHU plant.

The project duration was 12 months - split into 3 phases.

Location
Jaguar Land Rover, Gaydon
Main Contractor
SDC Builders Ltd
Services
  • Hot & Cold Domestic Services Systems
  • Air Conditioning
  • Ventilation Systems
  • Public Health
  • BMS & Controls
  • Hot & Cold Water
  • Low Temperature Hot Water System
  • Above Ground Drainage
  • Building Management System
Services Installed
Air Conditioning
BMS & Controls
Compressed Air Systems
Cooling Water
Public Health
Ventilation Systems
